Internal Combustion Explosion-proof Forklift 3.5T
Author:
Product Model and Parameters
Internal Combustion Explosion-proof Forklift 3.5T
Item Unit Parameter Item Unit Parameter
Application Site ：Zone1, 2, 21, 22
Lifting Speed (Loaded) mm/s ：350
Explosion-proof Grade of Whole Machine ：Ⅱ B T4 Gb/ⅢB T4
Maximum Climbing Gradient (Loaded) % ：18
Power Type ：Diesel
Wheelbase mm ：1700
Rated Lifting Capacity kg： 3500
Wheel Tread (Front/Rear) mm ：1000/980
Load Center Distance mm ：500
Minimum Ground Clearance mm ：140
Maximum Lifting Height mm： 3000
Front/Rear Tire Model (Anti-static)： 28x9-15/6.50-10
Free Lifting Height mm ：170
Battery Pack V/A.H ：12/90
Fork Length mm： 1070
Engine Model ：490BPG
Mast Tilt Angle (Forward/Backward) ：6/12
Rated Power/Rotational Speed kw ：37/2650
Overall Dimensions (Excluding Forks) mm： 2750x1210x2120
Number of Cylinders： 4
Minimum Turning Radius mm ：2450
Fuel Tank Capacity L ：70
Maximum Driving Speed (Loaded) km/h： 17
Self-weight kg ：4840
Maximum Driving Speed (Unloaded) km/h ：18
*The models and parameters involved in this page are for reference only. Please refer to the actual vehicle for specific information.
