304 Stainless steel fully electric stacker
Author:
1.Stainless steel fully electric stacker with a load capacity of 1000KG. The whole machine is made of 304 stainless steel, suitable for clean areas of pharmaceutical workshops.
2.The core control system of the forklift is the 1232E brand from Curtis, USA.
3.The fully electric stacker is equipped with a high-power lead-acid battery of 24V210AH, which supports fast charging, suitable for places with long working hours and durable.
4.The vehicle adopts an AC drive motor, suitable for warehouse workshops. It is operated in walking mode, with a short body, suitable for operations in narrow passages and limited spaces.
5.Each vehicle is equipped with one 24V30A charger, which automatically switches off after being fully charged.
6.The outer surface of the vehicle is processed by planing, whitening and passivation, with a surface cleanliness of up to 1/10000.
7.The vehicle uses a special stainless steel welding machine, and the whole machine is fully welded with welds, which is very beautiful.
304 Stainless steel fully electric stacker Feature
1.1 Item： Name Stainless Steel Fully Electric Stacker
1.2 Model ：CDD -1T
1.3 Mast Stages ： Single
1.4 Power Type ：Lead-acid Battery
1.5 Operation Type： Walking Type
1.6 Braking Method： Electromagnetic Braking
1.7 Rated Load Q(Kg) ：1000
1.8 Load Center Distance C(mm) ：600
1.9 Hydraulic Cylinder ：Double
1.11 Surface Treatment Planing, Whitening, Passivation and High Cleanliness Treatment
2 Application
2.1 Main Application Handling and stacking in warehouse workshops
3 Tire
3.1 Tire Type ： Polyurethane
3.2 Number of Drive Wheels, Balance Wheels/Load-bearing Wheels： 1, 2/4
4 Dimension
4.1 Lifting Height (mm) ：1600
4.2 Height after Fork Lowering (mm)： 90
4.3 Overall Height of Vehicle when Fork is at Maximum Height (mm)： 2000
4.4 Overall Length of Vehicle (mm) ：2000
4.5 Overall Width of Vehicle (mm)： 850
4.6 Fork Size l/e/s(mm)： 1100 in Length
4.7 Outer Width of Fork(mm) ：680
4.8 Front Wheel Size mm： Φ80*70
4.9 Drive Wheel mm： Φ250
4.10 Auxiliary Wheel Size mm： Φ150*50
4.11 Aisle Width Ast(mm)： 1000
4.12 Turning Radius mm： 1800
5 Performance
5.1 Travel Speed, Full Load/No Load km/h： 4/6
5.2 Lifting Speed, Full Load/No Load mm/s ：40/45
5.3 Lowering Speed, Full Load/No Load mm/s ：50/45
5.4 Climbing Ability, Full Load/No Load %： 5/8
5.5 Braking Distance, Full Load/No Load mm： 500/400
6 Drive
6.1 Power of Drive Motor W ：1500
6.2 Power of Lifting Motor Kw ：2.5
6.3 Voltage/Capacity of Lithium Battery V/Ah ：24/210
6.4 Charger Specification： 24V30A
6.5 Drive Wheel Type ：Horizontal Type
6.6 Steering System： Mechanical Steering
PS:There are also two door frame models that can be raised to a higher height. Please consult customer service for specific information
